High Efficient Juice concentration machine equipment

Juice concentration machine concentrator equipment Juice concentration machine concentrator equipment Product Description   Traditional Chinese medicine hot backset current low temperature draw low temperature concentrate unit comprehensive backset current, ooze and filter drawing, adverse current and hot backset current extraction and concentrate four kinds of principles. abstraction, concentrate two processes go on at the same time, one finish traditional medicine draw, concentrate the new craft of traditional Chinese medicine, take to change the draw pot keep high temperature with atmosphere fry the craft of boiling, utilize vacuum to shoulder proceed low temperature draw and low temperature concentrate, make working temperature to draw pot control in 60-80°C, concentrate temperature control in 50-70°C, guarantee crude drugs effective composition the distillation loss. Meanwhile draw and concentrate produced two steam enter backset current condenser become hot condensation liquid, falling back to and drawing it the pots, add to the crude drugs as the new solvent, the new solvent is passed the crude drugs layer from top to bottom, having played a oozing and filtering dynamically role, the soluble material which dissolves the crude drugs reaches the draw pot bottom, enter the concentrating device to concentrate again. According to practical experience and study for many years, hot condensation liquid of backset current invite within 2.5-3 hours drawing former solvent of pot all change once, can keep a higher density to the draw pot crude drugs in unit time.   Application  Thermal circumfluence extraction & concentration unit is suitable for extraction and concentration of traditional Chinese medicinal herbal. With this unit, it is able to extract and concentrate at the same time, rather than extract first and then concentrate like before.          How it Works - Put the prepared materials into the extracting tank, and add solvent 5-10 times the volume of the materials ( the actual type and the amount of solvent is according to the process requirement).

- After soaking for a certain while, open the steam valve to heat up, normally by jacket heating, steam heating is only for water extraction and drawing aromatic oil.

- After cooking for a certain while, pump the extraction solution into the concentrator.

- The steam produced during concentration goes to the condenser and is cooled down into condensate, and will go to the extracting tank as new solvent. And the secondary steam produced in the extracting tank is also cooled down by the condenser and falls back into the extracting tank. All the secondary steam produced will be fully used.    Technical Data

Model	LTN0.5/125	LTN1/250
The volume of extracting (m³)	0.5	1
Concentrating quantity(kg/h)	150	300
Raw Material Input Capacity (kg)	50-70	100-150
Capacity of Concentrating Evaporator	125kg/hour	250kg/hour
Water Circulation Capacity	8-15t	15-25t
The time of extraction (h)	6-8	6-8
Concentrate density (%)	1.2-1.35	1.2-1.35
The work temperature of extracting and concentrating (°C)	Water: 50-90°C Alcohol: 40-80°C	Water: 50-90°C Alcohol: 40-80°C
Power of Vacuum Pump	3kw	4kw
Whole Unit Size	5000*3000*5500mm	9000*4000*6000mm

      Details

	Multifunctional Extracting Pot
Electric Heating Force Recovery Tower
	Pourable Vacuum Concentrating Tank
Ball Type Vacuum Concentrating Tank

                                                                                  Finished Products:                                                                                                                                                                      Packaging & Shipping         Company Information   Certificate:        Our Team:     Our Customers:     Exhibitions:     Our Services   1.We have seven technicians who gets passport ready to travel all over world to offer service to you. 2.We have 24hours hot line for Technical Support.  3.We get 18hours internet line for technical support. 4.Video camera in workshop to help you adjust and solve machine problem in working situation.
