LTDG-10Y Stainless Steel Freeze Dryer Machine,Vacuum Freeze Dryer,Freeze Dryer China

Product Description

Products Description Freeze-dry (brief named Freeze-dry) is a stable process of material dried which will put the material contained with water to freeze to solid first, then make among them of the water sublimate from solid to air condition, removing water to preserve materials. Products at solution stage are frozen through sublimation and desorption, then the solvent reduce to a certain extent, thereby preventing the formation of micro-organisms or chemical reaction between the solute and solvent that products can be preserved for a long time and maintained its nature. Vacuum freeze-drying method is a liquid → solid → gaseous process. In freeze-drying process, "liquid bridge" between the solution particles has been frozen into "solid bridge". The relative position of particles has been fixed and does not exist surface tension on gas-liquid interface between the two particles. With the continuous distillation of solvent, "solid bridge" continuously decrease, but the the relative position between two particles will not longer change until the "solid bridge" completely disappear.
Product Paramenters
Freeze Drying machine
Unit
Production for Batch
LTDG-1
LTDG-50
LTDG-75
LTDG-100
Nominal Area
m2
1
50
75
100
Capacity
Area of the heat shelf
m2
1.08
59.9
89.9
110.1
Tray Area
1.02
50.2
75.8
101
Tray Size
mm
780*510*37
Total Volume Dehydration (Max)
Kg/batch
15
1000
1500
2000
Details Images Features Products Company Profile Q: What price terms you offer? A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request. Q: What payment terms you take? A: TT, LC, other terms are also workable. Q: Will you help with installation and stuff training? A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day. Q: How can I visit your factory? A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you! Any other doubts about our machine, please feel easy to contact with us.

Contact us if you need more details on Vacuum Freeze Dryer. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Freeze Dryer Machine、Freeze Dryer. If these products fail to match your need, please contact us and we would like to provide relevant information.
